PCB CAM Engineering Services

Complete data preparation services to ensure manufacturing-ready PCB files

Data Import

Data Import & Verification

We receive and validate your PCB design data, ensuring completeness and manufacturability before processing begins.

  • Import Gerber (RS-274X), ODB++, DXF, and other standard formats
  • Verify data completeness against job requirements
  • Assess manufacturability limits and constraints
  • Prepare clarification notes per agreed templates
  • Complete quote request forms per customer systems
Layer Processing

Layer Processing & Optimization

Expert layer alignment, attribute assignment, and optimization for accurate manufacturing output.

  • Precise alignment of all PCB layers
  • Layer renaming per pre-defined conventions
  • Assign layer and feature attributes
  • Drawn-to-flash pad conversions
  • Contour drawn or filled areas
  • Customer-specific CAM operations
DRC Validation

DRC & Error Repair

Comprehensive Design Rule Checks and error repair to ensure manufacturing success.

  • DRC per customer-defined rules and tolerances
  • Repair DRC errors following customer guidelines
  • Eliminate slivers, acid traps, and pinholes
  • Verify spacing and clearance requirements
  • Check annular ring and via specifications
Manufacturing Prep

Manufacturing Preparation

Complete preparation of all manufacturing layers and production-specific requirements.

  • Modify or generate drill layers per tolerances
  • Apply etch compensation as required
  • Repair or generate solder mask layers
  • Silkscreen (legend) clipping and optimization
  • Generate job-specific layers (peelable, carbon, gold plating)
  • Add logos, markings, and date codes
Panelization

Panelization & Array Creation

Optimized panel layouts and routing profiles for efficient manufacturing.

  • Create route profiles optimized for manufacturing
  • Palletization and array creation per job requirements
  • Panelization based on customer panel frames
  • Add fiducials, tooling holes, and panel markings
  • Generate breakaway tabs and scoring lines
Output Delivery

Output & Delivery

Final validation and secure delivery of manufacturing-ready CAM data.

  • Output in ODB++ format
  • Output in Gerber (RS-274X) format
  • Customer-required output formats
  • Final validation and quality verification
  • Secure delivery with complete documentation
